Part No.: 43140312HYY10C
Rated current: 7A
Rated voltage: 250V
Pitch: 3.0mm
Number of potentials: 2*6
Number of row: 2
| Electrical parameters | Remark | ||
| Rated current | 7A | ||
| Rate voltage （III/2） | 250V | ||
| Impulse withstand voltage（III/2） | 1.5KV | ||
| Structure characteristics | |||
| Pitch | 3.0mm | ||
| Number of potentials | 2*6 | ||
| Number of rows | 2 | ||
| Material Data | |||
| Conform of RoHS | YES | ||
| Insulation material | PA66 | ||
| Contact material | Copper alloy | ||
| Plating of conductor surface | Tin-plated | ||
| Flammability Rating | UL94V-0 | ||
| Environmental Data | |||
| Ambient Temperature | -40℃ to 105℃ | ||
| Soldering Method | Wave Soldering | ||
| Industry Standard | |||
| Test Specification | UL1977/IEC61984 |
