Part No.: 5SM-M12B-05P-MM-SL8AXX-00AH
Interface type: Type B, Board Mount,M12
Installation mode: Plastic molding, Front fastened
Number of potentials: 3
| Main parameter | Remark | ||
| Installation mode | Plastic molding, Front fastened | ||
| Interface type | Type B,Board Mount, Male | ||
| Thread specification | M12 | ||
Fixed screw thread | PG9/M16*1.5 | ||
| Mating Endurance | ＞100 | ||
| Number of potentials | 5 | ||
| Torsional moment | 0.4N.m | ||
| Electrical parameters | |||
| Rated current | 4A | ||
| Rate voltage | 60V | ||
| Impulse withstand voltage | 1.5KV | ||
| Insulation resistance | ≥100MΩ | ||
| Cable data | |||
| Cable Jacket | PUR/PVC | ||
| Wire size | 0.34mm²*5 | ||
| Cable length | 1m，2m....99m | ||
| Flammability Rating | Conform with UL 758/1581 FT1 | ||
| Material data | |||
| RoHS Conform of RoHS | YES | ||
| Insulation material | PA66 | ||
| Contact material | Copper alloy | ||
| Plating of conductor surface | Gold-plated | ||
| Connector Overmold | TPU | ||
| Fastener material | Copper alloy Nickel Plated | ||
| Environmental data | |||
| Ambient temperature | -25℃-85℃ | ||
| IP Class | IP68 | ||
| Industry standard | |||
| Test Specification | IEC61076 |
