Part No.: 43000809HYY10C
Rated current: 12A
Rated voltage: 600V
Pitch: 6.35mm
Number of potentials: 3*3
Number of row: 3
| Electrical parameters | Remark | ||
| Rated current | 12A | ||
| Rate voltage （III/2） | 600V | ||
| Impulse withstand voltage（III/2） | 5.0KV | ||
| Structure characteristics | |||
| Pitch | 6.35mm | ||
| Number of potentials | 3*3 | ||
| Number of rows | 3 | ||
| Material Data | |||
| Conform of RoHS | YES | ||
| Insulation material | PA66 | ||
| Contact material | Copper alloy | ||
| Plating of conductor surface | Tin-plated | ||
| Flammability Rating | UL94V-0 | ||
| Environmental Data | |||
| Ambient Temperature | -40℃-105℃ | ||
| Soldering Method | Wave Soldering | ||
| Industry Standard | |||
| Test Specification | UL1977 |
