Part No.: 43110309YY10A
Pitch: 3.0mm
Number of potentials: 9
Number of row: 1
| Structure characteristics | Remark | ||
| Product type | Connector-male housing-plug | ||
| Connector serial | Wire to wire, Wire to board | ||
| Assitant lock system available | Yes | ||
| Pitch | 3.0mm | ||
| Number of potentials | 9 | ||
| Number of rows | 1 | ||
| Electrical parameters | |||
| Rated voltage | 250V | ||
| Insulation resistance | ≥1000MΩ | ||
| Material data | |||
| RoHS conform | YES | ||
| Plastic material | PA66 | ||
| Flammability rating | Tin-plated | ||
| Environmental data | |||
| Ambient temperature | -40℃-105℃ | ||
| Industry standard | |||
| Test specification | UL1977/IEC61984 |
